"XXL" Palletizing Gantry Robot

Large XYZ Gantry is ideal for Palletizing in Manufacturing and Logistics Industries

Large XYZ gantry robots are three-axis linear, cartesian robots that can be used for various pick and place applications, but are especially ideal for large, heavy loads such as lifting and moving pallets. These large gantries are used in various industries to transport high volumes and quantities of materials across warehouses and manufacturing facilities. Specifically, palletizing gantry robots are most frequently used in industries such as food and beverage, retail, manufacturing, logistics and more. These cartesian robots have three axes that slide linearly in relation to each other, rather than rotate as with a robotic arm. Because of this, larger work spaces can be covered with high positioning accuracy, making them especially ideal for lifting and moving pallets containing heavy loads across large distances within factories and warehouses.

Technical Data:

Workspace 2000 x 2000 x 1000mm
Payload up to 10kg
Repeatability ±0.8mm
Speeds up to 500mm/s

Benefits:

Maintenance-free, self-lubricating dry operation
Quiet, dirt/dust/corrosion-resistant and modular
Low assembly costs with easy installation
Less downtime & lower maintenance costs

Browse the Shop

Gantry Configurator

With the gantry configurator (beta version), you can configure any type of gantry, whether XY Actuator (Single Rail), XY Gantry or XYZ gantry. Customize to your unique specifications, requirements and size, and download or add to cart for purchase.

Use the Gantry Configurator

iRC - Robot Control Software

The igus® Robot Controller (iRC) enables you to control a gantry robot, delta robot, an igus® robotic system, SCARA or ReBeL as well. With the corresponding free software, you can easily program and move the robot via a graphical user interface.

Browse the Software
