e-loop® | modular e-chain® cable carrier
An alternative to service loops
For the cable guidance in top drive systems of undefined, manufacturers and operators have so far been using so-called "service loops". However, these often create problems. The cables have no guidance, no defined bend radius, can slip in the service loop and in the worst case, break. In extremely windy conditions, the freely hanging service loop can get caught in the mast or on the sensors as well as the lighting system and be critically damaged. Replacement of the entire cable package is necessary.
White paper: cable guiding in vertical drilling rigs
A newly developed alternative to the service loops on vertical drilling rigs offers significantly longer service life under extremely unfavorable environmental conditions. In this white paper, you can find the following topics:
- Application areas of the e-loop
- State of the art in the service loop
- Crash test for energy chains
- Modular system, easy to open
- No loose parts with optional screw lock
- Maximum cable/hose outer diameter up to 76mm or 500mm bend radius
- Protects against impact due to robust PU outer body
- Offers operational reliability due to secondary locking tension of all bolted connections
- Resistant to dirt
- An optional "drop safe" version is also available, with additional screw locking - as well as a stainless steel version
- Weather-resistant
- Easy maintenance
- Mounting brackets for easy and fast installation
- All components are individually replaceable
- Cable-friendly two-chamber interior separation system
- Fail-safe cables with 4 year guarantee
- Permitted 50kN operating load of the plastic rope
- Resistance to vibration and weather tested in the laboratory
- Shock-resistant and shatter-proof
- Structure of the e-loop is "Drop Safe" due to double screw locking of the parts
- Design based on the standard e-loop®, which has already demonstrated its resistance to weathering and vibration at 150,000DH
- Protects against impact due to robust PU outer body
- Delivery time from 6 weeks
- Have your e-chain® recycled at the end of its life cycle with the igus chainge recycling program. No matter what manufacturer.
- igus® has been an investor in Mura Technology from the beginning and is helping advance chemical recycling. From plastic waste to crude oil in 20 minutes.
Request e-loop® as an alternative to the service loop
NEW: e-loop® for Top-Drive-applications
The new e-loop® 'ELP.TD.300' is a four-part design for hanging top drive applications. Cables in hanging undefined are protected and routed safely. Lines can be easily filled through the opening on the side.
Dynamic, full-webbed | for almost all applications
| Part No. | Inner width Bi [mm] | Outer width Ba [mm] | Bend radius [mm] | Max filling weight [kg/m]¹ |
|---|---|---|---|---|
| ELP.220.01.D | 150 | 220 | 380 | 50 |
| ELP.300.01.D | 230 | 300 | 500 | 50 |
| ELP.430.01.D | 360 | 430 | 625 | 70 |
| ELP.TD.300.* | 230 | 300 | 500 | 50 |
Static, semi-rigid | for purely static cable routing
| Part No. | Inner width Bi [mm] | Outer width Ba [mm] | Bend radius [mm] | Max filling weight [kg/m]¹ |
|---|---|---|---|---|
| ELP.220.01.S | 150 | 220 | 175 | 50 |
| ELP.300.01.S | 230 | 300 | 210 | 50 |
NEW: First TopDrive e-chain cables with DNV approval
Reduction of costs by approx. 35% due to waiving the need to manufacture one-off products for projects.
Structure of the e-loop®
As an alternative to the service loop, the e-loop® combines the advantages of a polymer e-chain® with those of a plastic-fiber rope that possesses high tensile strength. Ideal for the tensile forces are absorbed by the rope and passed through the mounting brackets into the support structure. As a result, the cables are completely free of strain. The modular e-loop® made of high-performance plastics ensures a defined bend radius of the cables and withstands vibrations and shocks.
e-loop® FAQ
igus® has developed the e-loop® as an alternative to the service loop so that cables with large cross sections and heavy weights can be guided safely in hanging applications. The energy supply system is a round, three-dimensional modular system that can move strain-relieved cables with a defined bend radius. The cables can be used individually and replaced in case of maintenance. The chain links are also replaceable at any time.
The new energy supply system from igus® is built around a high-strength plastic rope that absorbs the tensile forces of the cables. The rope is composed of a synthetic plastic fiber and is therefore shatter-proof, weather-resistant, flexible and corrosion-free.
Unhook, lay down, unscrew, exchange cable(s), screw shut, remount. That's all it takes regarding maintenance thanks to the simple modular setup of the e-chain®. For the rarest of cases you should always have a replacement chain at hand to avoid downtime.
igus® delivers the e-loop® in the way that you prefer: either completely assembled or fully harnessed, on a drum or on a pallet. There is a defined thread at the end of the e-loop® for additional mounting. Our installation team is happy to take care of the assembly.
The individual chain links are all secured with screw connections, so that no component can fall down.
The e-loop® can be used in the following branches of industry:
